Lemon Juice Concentration Decanter Industrial Centrifuge Machine Low Noise

ZHANGJIAGANG CITY PEONY MACHINERY CO.,LTD
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment

Lemon Juice Concentration Decanter Industrial Centrifuge Machine Low Noise

  • 1
  • 2

Brand Name : Peony

Model Number : PDC

Certification : ISO9001& ISO14001

Place of Origin : China

MOQ : 1 set

Price : USD28000-100000/SET FOB SHANGHAI

Payment Terms : TT,.LC, Western Union

Supply Ability : 60 sets per month

Delivery Time : 60-90days after receiving the down payment

Packaging Details : Standard wooden case

Application : Liquid Solid Separation

Structure : Horizontal

Operation : Automatic, continuous

Separation : Liquid-solid 2 phase

Wet parts : SS304, SS316L as optional

Bearing : SKF, NSK, etc

Motor : ABB, Siemens, etc.

Control box : With Control Box

Color : Blue or customized

Contact Now

Large Capacity Continuous Decanter Centrifuges for Fruit Juice Clarifying

Description

The machine could deal with the material which range of concentration is large, small size which widely distributing. Solid particles are less 0.5mm as rigid particles, and less than 10mm as non-rigid particles, the machine can be effectively treated.

Technical parameters

Model Drum G-force

Capacity

(m3/h)

Max solid

discharge
(m3/h)

Power
(kw)
Weight
(kg)

Overall size
(L*W*H)

(mm)

Dia.

(mm)

Length

(mm)

Speed

(rpm)

PDC-10-W 250 1000 5400 4080 0.5~5 0.4 11/4 1000 2410*800*1080
PDC-12-4-W 300 1200 4200 3500 1~5 0.6 11/4 1200 2610*800*1080
PDC-12-4.5-W 300 1350 4200 3000 1~10 0.8 11/4 1400 2760*800*1080
PDC-14-W 355 1600 4000 3180 1~20 1.2 18.5/7.5 1800 3495*840*1180
PDC-16-W 400 1800 3650 3000 2~25 2 22/7.5 2500 3890*1020*1205
PDC-17-4.4-W 450 2000 3200 2600 3~35 2.8 30/11 3000 4297*1080*1385
PDC-17-4.8-W 450 2150 3200 2600 4~40 3 37/11 3200 4447*1080*1385
PDC-20-4-W 500 2000 3000 2500 5~45 3.2 37/11 3800 4330*1140*1470
PDC-20-4.5-W 500 2250 3000 2500 8~50 3.5 45/15 4000 4580*1140*1470
PDC-21-W 530 2280 2900 2500 15~65 5 55/15 5000 4924*1170*1540
PDC-23-W 580 2500 2780 2500 20~80 6.5 75/18.5 6500 5205*1270*1540
PDC-26-W 650 2800 2500 2270 25~110 8 75/18.5 7000 4300*1900*1350

Applications

Food: Fruit and Vegetable juices, Starch, Protein, Molasses, Stillage
Oils and Fats: Fish oil, Gelatine
Environmental protection/Recycling: Drilling mud, Industrial wastewater, Municipal wastewater
Minerals: Graphite, Kaolin, Bentonite

More pictures

Lemon Juice Concentration Decanter Industrial Centrifuge Machine Low NoiseLemon Juice Concentration Decanter Industrial Centrifuge Machine Low Noise

Lemon Juice Concentration Decanter Industrial Centrifuge Machine Low Noise

Guarantee:

Peony Centrifuge has been dedicated to producing machinery and equipments and carrying out facility construction, pursuing the best quality and producing the best product at the same time. We are committed to reward you with a better quality in return for our interest in and faith toward. We will do our utmost for one more stepping forward, based on our infinite services and trust to customers.
